Zenith 1520
Ligne: 8.75'''
Jewels: 15
Power Reserve: 34 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1925
Diameter: 19.7 mm
Height: 3.4 mm
Hands: 1.20 x 0.60 / 0.11 mm
The Zenith 1520 is a manual wind watch movement with a sub second function that was commonly used around 1925. While there are different bridge shapes and variations among other models, the specific differences between the Zenith 1520 and other movements such as the 60-III, 61 through 64, 68, 72, 77, 81, 86, 96, 99, 102, 104, 107, 108, and 154 are not known.
The Zenith 1520 features the following functions:
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.50 x 0.080 x 215 x 7.0 mm | Manual | Buy mainspring | |
| 1.40 x 0.085 x 220 x 7.0 mm | GR3613 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
