Valjoux 321
Ligne: 12.5'''
Jewels: 6
Power Reserve: 30 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1900
Diameter: 28.4 mm
Hands: 1.55 x 0.48 mm
The Valjoux 321 is a mechanical watch movement utilizing a cylinder escapement. It features a crown mechanism with a rocker bar and a ratchet on the back side. However, it is unclear if the completely functionless crown wheel is a standard component. The movement offers stem wind and pin set functions and was primarily used during the period around 1900.
The Valjoux 321 features the following functions:
- Stem wind and pin set
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.50 x 0.140 x 300 x 11.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
