UTC-Unitime 233
(Unitime)
Ligne: 11.5'''
Jewels: 17/21/22
Power Reserve: 38 hrs
Frequency: 18000 vph
Type: Automatic
Diameter: 26 mm
Height: 5.75 mm
Hands: 1.30 x 0.90 x 0.20 mm
Base: A. Schild 1361
The UTC-Unitime 233 is a detached manual wind watch movement that is sometimes found with different rotor shapes. The specific differences between the 1361N, 1457N, 1490, and 1519 variations are not known. The movement features automatic winding and a sweep seconds function.
The UTC-Unitime 233 features the following functions:
- Automatic Winding
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 3605 | Ordinary/None | Buy staff |
| 5479 | Incabloc | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.45 x 0.100 x 280 x 8.5 mm | GR3952X | Auto | Buy mainspring |
| 1.45 x 0.100 x 250 x 8.5 mm | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
