Unitas 6310
Ligne: 13'''
Jewels: 15/17
Lift Angle: 49°
Power Reserve: 47 hrs
Frequency: 18000 vph
Type: Array
Diameter: 29.4 mm
Height: 3.85 mm
Hands: 1.50 x 0.90 / 0.21 mm
The Unitas 6310 watch movement, also known as the Wehrmachtswerk (Germany Military Movement), features an early fixed, later mobile stud carrier. The differences between the 6310 through 6318 models are unknown, but they likely represent varying bridge shapes. This movement is a manual wind mechanism with sub-second functionality.
The Unitas 6310 features the following functions:
- Manual Winding
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 2394 | Ordinary/None | Buy staff |
| 4871 | Ordinary/None | Buy staff |
| 2738 | Incabloc | Buy staff |
| 5161 | Incabloc | Buy staff |
| 3141 | Supershock | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.75 x 0.135 x 360 x 11.5 mm | GR5171 | Manual | Buy mainspring |
| 1.70 x 0.130 x 360 x 11.5 mm | Manual | Buy mainspring | |
| 1.70 x 0.130 x 340 x 11.0 mm | GR4958 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
