Unitas 33
Ligne: 9'''
Jewels: 17/18
Lift Angle: 52°
Power Reserve: 42 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1960
Diameter: 20.8 mm
Height: 1.75 mm
Hands: 1.00 x 0.50 mm
Base: Omega 700
The Unitas 33 watch movement features an escapement wheel in Kif Duofix. This movement is a manual wind type and was predominantly used in watches produced around the 1960s.
The Unitas 33 features the following functions:
- Manual Winding
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|---|---|---|
| ESCAPE WHEEL, C/S | 704/290 | 704/290 | Buy part |
| MAINSPRING, WHITE-A-LOY | MS-4011HC | Buy part | |
| SET BRIDGE | 445/1176 | 445/1176 | Buy part |
| STAFF | 100/2229 | Buy part | |
| STEM, TAP 10 | 200/1625F | Buy part |
