Unitas 153
Ligne: 11.5'''
Jewels: 7
Power Reserve: 47 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1969
Diameter: 26 mm
Height: 3.75 mm
Hands: 1.50 x 0.90 x 0.21 mm
Base: Diehl 620
The Unitas 153 is a budget version of the Junghans-620 family movement designed for Diehl watches. It features a barrel with a jewel bearing only on the dial side and utilizes a plane 3(4 plate. It is a manual wind movement with a sub second function. The Unitas 153 movement was commonly used in watches produced around 1969.
The Unitas 153 features the following functions:
- Manual Winding
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.15 x 0.120 x 320 x 10.5 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
