Ulysse Nardin 8
(UN)
Jewels: 15
Power Reserve: 34 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: 1911-1912
Diameter: 43.15 mm
Height: 5.15 mm
Hands: 1.65 x 0.92 / 0.22 mm
The Ulysse Nardin 8 watch movement, produced between 1911-1912, consisted of approximately 21000 units. It featured a hunter calibre, model 2, with a base plate composed of two parts, likely one adapted to tools for 12 size. The movement incorporated a bimetallic screw balance and a Breguet hairspring. It also employed a negative stem mechanism with an adjustable switching point. Its primary functions included stem winding and a sub-second display.
The Ulysse Nardin 8 features the following functions:
- Stem wind
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 2.05 x 0.200 x 520 x 15.5 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
