Tissot 783
Ligne: 12.5'''
Jewels: 21
Lift Angle: 46°
Power Reserve: 41 hrs
Frequency: 21600 vph
Type: Automatic
Period used: 1971-
Diameter: 28.4 mm
Height: 4.8 mm
The Tissot 783 watch movement, utilized from 1971 onward, incorporates jewel bearings for the barrel. Its functions include automatic winding, 12-hour and 24-hour display from the center, sweep seconds hand, quickset date, and a hack feature.
The Tissot 783 features the following functions:
- 12h- und 24h-Anzeige aus der Mitte
- Automatic Winding
- Date: quickset
- Hack feature
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|---|---|---|
| PALLET FORK AND ARBOR | 035-39 | 710/1344 | Buy part |
| ROLLER | 044-02 | 730/64 | Buy part |
| STEM, GENUINE | 065-99 | 401/766 | Buy part |
