Savoie P72A
(Lorsa)
Ligne: 17'''
Jewels: 15
Lift Angle: 36°
Frequency: 18000 vph
Type: Manual Wind
Period used: 1949-
Diameter: 39.1 mm
Height: 4.9 mm
Hands: 1.90 x 1.25 / 0.21 mm
The Savoie P72A is a mechanical watch movement that was produced by Omega during the period of 1949 onwards. It is an open face calibre movement with a Breguet hairspring. This movement is stem wind and set, and also features a sub second function. The Savoie P72A was derived from the Omega 38.5L T1 movement, which was renamed to Omega 160 during production.
The Savoie P72A features the following functions:
- Stem wind and set
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 2.10 x 0.180 x 440 x 14.5 mm | GR6058 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|---|---|---|
| BARREL | 182/807 | 1200/OME 161 | Buy part |
| BARREL ARBOR | 195/844 | 1204/OME 160 | Buy part |
| CENTER WHEEL | 201/884 | 1224/OME 161 | Buy part |
| CLICK | 425/349 | 1104/OME 160 | Buy part |
| CLICKSPRING | 430/874 | 1105/OME 150 | Buy part |
| ESCAPE WHEEL, S/S | 705/903 | 1305/OME 160 | Buy part |
| FOURTH WHEEL, W/SECOND | 224/537 | 1243/OME 161 | Buy part |
| JEWEL, UPPER BALANCE CAP | 311/305 | 1329/OME 160 | Buy part |
| MAINSPRING 12-5-17.5 | 770/19 | 1208/OME 160 | Buy part |
| PALLET ARBOR | 714/49 | 1312/OME 150 | Buy part |
| PALLET FORK & ARBOR | 710/1021 | 1316/OME 161 | Buy part |
| RATCHET WHEEL | 415/770 | 1100/OME 160 | Buy part |
| ROLLER | 82S/335R | 82S/335R | Buy part |
| SCREW, CASE | 5101/OME 161 | 2708/OME 161 | Buy part |
| SCREW, DIAL SIDE | 5750/219 | 2167/OME 140 | Buy part |
| SCREW, RATCHET WHEEL | 5415/443 | 2148/OME 160 | Buy part |
| STAFF | 723/403 | 1321/OME 150 | Buy part |
| STAFF | 100/842 | 1321/OME 150 | Buy part |
| STEM | 401/217 | 1106/OME 150 | Buy part |
| STEM | 200/674F | Buy part | |
| THIRD WHEEL | 210/956 | 1240/OME 161 | Buy part |
| UP BALANCE CAP JEWEL LOCK | M/1695 | 1335/OME 160 | Buy part |
| WIND PINION | 1108/OME 161 | Buy part |
