Revue GT12
Ligne: 11.5'''
Jewels: 17
Power Reserve: 48 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1965
Diameter: 26 mm
Height: 4.5 mm
Hands: 1.30 x 0.90 x 0.21 mm
The Revue GT12 watch movement, also known as FHF-ST, belongs to a series of movements that include the 961, 962, 963, 964, 965, and 969. Although the specific differences between these movements are not known, they share similar characteristics and functions. The movement is manually wound and features a sweep second hand. It was commonly used during the period around 1965.
The Revue GT12 features the following functions:
- Manual Winding
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 1007 | Ordinary/None | Buy staff |
| 4841 | Incabloc | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.60 x 0.120 x 350 x 11.0 mm | Manual | Buy mainspring | |
| 1.60 x 0.110 x 400 x 10.5 mm | GR4519 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
