Revue 78
Ligne: 16'''
Jewels: 7/15
Power Reserve: 34 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1950
Diameter: 36 mm
Height: 5.1 mm
Hands: 1.40 x 0.60 / 0.24 mm
The Revue 78 is an open face calibre watch movement that was in use around the year 1950. It features a unique crown mechanism with a rocker bar positioned between the plates. The movement includes functions such as stem winding and setting, as well as a sub second hand.
The Revue 78 features the following functions:
- Stem wind and set
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 1104 | Ordinary/None | Buy staff |
| 1897 | Ordinary/None | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.60 x 0.170 x 14.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
