Recta G10
Ligne: 5.75 x 8.5'''
Jewels: 17/21
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1950
Diameter: 19.15 mm
Height: 3.65 mm
Hands: 1.00 x 0.53 mm
The Recta G10 watch movement is almost identical to the TE 10 caliber. It is a manual wind movement that was commonly used around the 1950s.
The Recta G10 features the following functions:
- Manual Winding
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.25 x 0.090 x 240 x 7.5 mm | GR3095 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
