Puw 63
Ligne: 12'''
Jewels: 15
Power Reserve: 47 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: 1947-1955
Diameter: 27.25 mm
Height: 3.85 mm
Hands: 1.30 x 0.75 / 0.18 mm
The Puw 63 watch movement, manufactured between 1947 and 1955, had a production volume of 327,000 units. It is a manual wind movement with a sub second function.
The Puw 63 features the following functions:
- Manual Winding
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 2751 | Ordinary/None | Buy staff |
| 2751 | Incabloc | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.55 x 0.100 x 380 x 10.0 mm | GR4384 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
