Omega 30.10T1RAPC
Ligne: 11.5'''
Jewels: 23
Power Reserve: 46 hrs
Frequency: 21600 vph
Type: Automatic
Period used: 1968-
Diameter: 26 mm
Height: 4.35 mm
Hands: 1.50 x 0.90 x 0.20 mm
The Omega 30.10T1RAPC is a mechanical watch movement with a period of use starting from 1968. It features Diafix combined settings for the escape wheel and third wheel, allowing for improved stability. The winding gear is integrated within the movement itself, as opposed to being attached to a manual-wind calibre. This design choice contributes to a rugged movement with a relatively large balance and low profile. In addition, the Omega 30.10T1RAPC movement offers various functions, including automatic winding, a sweep second hand, and a hack feature. It also includes an Adjustable Stud Holder and Shock Protection for enhanced durability.
The Omega 30.10T1RAPC features the following functions:
- Adjustable Stud Holder
- Automatic Winding
- Hack feature
- Shock Protection
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.10 x 0.120 x 340 x 10.5 mm | GR2653X | Auto | Buy mainspring |
| 1.10 x 0.118 x 340 x 10.0 mm | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
