New Factory Tavennes 50
(Tavennes)
Ligne: 12'''
Jewels: 1
Lift Angle: 42°
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1980
Diameter: 27.64 mm
Hands: 2.00 x 1.20 mm
The New Factory Tavennes 50 watch movement, introduced around 1980, features a pin-lever escapement and an indirect minute hand friction clutch on the barrel. It is a manual wind movement with a sub-second function.
The New Factory Tavennes 50 features the following functions:
- Manual Winding
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.25 x 0.125 x 14.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
