Movado 48
Ligne: 8.75'''
Jewels: 15
Power Reserve: 33 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1925
Diameter: 19.8 mm
Height: 3.3 mm
Hands: 1.10 x 0.65 mm
Base: ETA 361
The Movado 48 watch movement is a manual wind movement with a sub second function. It was introduced around 1925 and belongs to a set of movements numbered 361-367, 500, 501, and 505-509. Further details regarding the specific differences between these movements are not known.
The Movado 48 features the following functions:
- Manual Winding
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.20 x 0.085 x 240 x 7.0 mm | GR2885 | Manual | Buy mainspring |
| 1.20 x 0.080 x 220 x 7.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|---|---|---|
| SCREW SET LEVER *UA* | Buy part | ||
| STEM | 401/ETA 500 | Buy part |
