Mido 700B
Jewels: 21
Power Reserve: 34 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: 1895-1899
Diameter: 43.1 mm
Height: 6.65 mm
Hands: 1.65 x 0.92 / 0.25 mm
The Mido 700B watch movement, produced from 1895-1899, is an open-face calibre model 7 with a bimetallic screw balance and a Breguet hairspring. It features a negative stem mechanism and allows for switching between winding and setting in the lever position. The movement includes functions such as stem wind with switching possible through the crown or lever, as well as a sub-second display.
The Mido 700B features the following functions:
- Stem wind, switching by crown or lever
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 2.60 x 0.205 x 540 x 17.0 mm | GR6806DBH | DBH | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
