Mido 0917
Ligne: 6.5'''
Jewels: 17
Lift Angle: 51°
Power Reserve: 45 hrs
Frequency: 19800 vph
Type: Automatic
Period used: 1961-1973
Diameter: 15.4 mm
Height: 4.25 mm
Hands: 0.90 x 0.50 mm
The Mido 0917 watch movement, manufactured between 1961 and 1973, featured a ratcet wheel made of beryllium bronze and different rotor shapes. It holds the distinction of being the smallest ever industrial manufactured automatic movement in terms of volume, and it efficiently utilizes available space. The movement is automatic and was used during the specified period.
The Mido 0917 features the following functions:
- Automatic Winding
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 0.96 x 0.060 x 230 x 5.5 mm | Auto | Buy mainspring | |
| 0.95 x 0.065 x 220 x 6.0 mm | GR2370X | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
