Mido 0617P
Ligne: 11.5'''
Jewels: 17
Lift Angle: 53°
Power Reserve: 40 hrs
Frequency: 36000 vph
Type: Automatic
Period used: 1974-1975
Diameter: 26 mm
Height: 5.1 mm
Hands: 1.50 x 0.90 x 0.25 mm
The Mido 0617P watch movement, introduced during the years 1974-1975, is an automatic movement with a sweep second hand. It features a quickset mechanism for adjusting the day and date displays. Additionally, it includes a hack feature, allowing for precise time synchronization.
The Mido 0617P features the following functions:
- Automatic Winding
- Date: quickset
- Day and Date Display
- Day: quickset
- Hack feature
- Sweep second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.25 x 0.125 x 420 x 10.5 mm | GR3149X | Auto | Buy mainspring |
| 1.23 x 0.134 x 400 x 10.5 mm | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
Documents
Parts Listing
