Marvin 580C
Ligne: 11.5'''
Jewels: 21/25
Power Reserve: 38 hrs
Frequency: 21600 vph
Type: Automatic
Period used: 1972-
Diameter: 26 mm
Height: 5.3 mm
Hands: 1.50 x 0.90 x 0.21 mm
The Marvin 580C watch movement was introduced in 1972 with several notable features. In early samples, it featured a separate click and click-spring, but later versions incorporated a single-part click. This movement offers various functions, including automatic winding, sweep seconds, and a quickset date. It has been utilized since 1972 and is still found in watches today.
The Marvin 580C features the following functions:
- Automatic Winding
- Date: quickset
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.30 x 0.100 x 340 x 10.0 mm | GR3256X | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More | |||
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
