Longines 8L
Ligne: 11.5'''
Jewels: 17
Power Reserve: 43 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1950
Diameter: 26 mm
Hands: 1.30 x 0.70 / 0.22 mm
Base: Fontainemelon 70
The Longines 8L is a mechanical watch movement that shares similarities with the 70-3, albeit with a larger pillar plate. This movement is manually wound and features a sub-second function. Additionally, it includes a date hand that can be set by adjusting the 20-24 hour range. The Longines 8L movement was commonly used around the 1950s.
The Longines 8L features the following functions:
- Date hand: set by changing 20-24h
- Manual Winding
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.70 x 0.100 x 315 x 9.5 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
