Longines 10.86
Ligne: 11.5'''
Jewels: 17
Lift Angle: 54°
Power Reserve: 50 hrs
Frequency: 28800 vph
Type: Manual Wind
Period used: 1971-1980
Diameter: 26 mm
Height: 4.0 mm
Hands: 1.50 x 0.90 x 0.25 mm
The Longines 10.86 is a mechanical watch movement that was produced between 1971 and 1980, with a total of 6,156,000 units manufactured during this period. It is a manual wind movement that features a sweep second hand, and it offers the option for a hack feature.
The Longines 10.86 features the following functions:
- Manual Winding
- Option: Hack feature
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.45 x 0.130 x 400 x 11.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|---|---|---|
| JEWEL, INCA BALANCE 135X50X09 | 400/11 | 111.09/INCA#8 | Buy part |
| JEWEL, UPPER CAP INCA 120X18 | 400/8 | 122.11/INCA #6 | Buy part |
| SHOCK SPRING, LOWER 223 X 155 | 400/811 | 173.03/INC | Buy part |
| SHOCK SPRING, UPPER INCABLOC | 400/4 | 170.03/INCA #1 | Buy part |
| SHOCK UNIT, LOWER | 400/1851 | 163.20.09 | Buy part |
| SHOCK UNIT, UPPER 312 X .09 | 400/1857 | 163.22.312.09 | Buy part |
