Longines 10.85
Ligne: 13.5'''
Jewels: 17
Power Reserve: 41 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: 1973-1974
Diameter: 30.45 mm
Height: 6.8 mm
Hands: 1.50 x 0.90 x 0.25 / 0.20 x 0.20 mm
The Longines 10.85 watch movement is a pin-lever escapement with an indirect minute hand friction clutch on the barrel. It is part of a family of movements with several variants, but due to poor documentation, only known variants are currently listed. The movements in this family are typically signed with the designation of the most frequently produced variant, with attached codes for features if the official designation is unknown. The Longines 10.85 movement includes a range of functions such as manual-wind chronograph (60s, 15min, cam switched), manual wind, sub second, quickset date (reverse setting), sub seconds, chronograph, pin lever, and calendar. This movement was used during the period of 1973-1974.
The Longines 10.85 features the following functions:
- Calendar
- Date: quickset by reverse setting
- Manual Winding
- Manual-wind chronograph, 60s, 15min, cam switched
- Pin lever
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.50 x 0.080 x 240 x 7.0 mm | GR4076 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
