Kienzle 46/15
Jewels: 7/11/15/17/19/21/23
Power Reserve: 35 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: 1899-1908
Diameter: 41.4 mm
Height: 6.4 mm
Hands: 1.90 x 1.18 / 0.25 mm
The Kienzle 46/15 watch movement, manufactured from 1899 to 1908, is a hunter calibre with a pink gold center wheel. It features a bimetallic screw balance with a Breguet hairspring, a partially fine regulation gear, and a safety barrel. The movement includes stem winding, which can be switched by the crown or lever, and a sub-second function.
The Kienzle 46/15 features the following functions:
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 4439 | Ordinary/None | Buy staff |
| 2525 | Ordinary/None | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 2.90 x 0.180 x 17.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
