Kienzle 07730
Ligne: 11.5'''
Jewels: 17
Power Reserve: 39 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1945
Diameter: 26 mm
Height: 4.6 mm
Hands: 1.40 x 0.80 x 0.20 mm
The Kienzle 07730 watch movement is part of a family of movements that includes the Femga 500, 502, 520, and other Precimax models such as the 250, 250SC, and 400. It is unclear whether there is any relationship between the French Femga and the Swiss Precimax movements. The Kienzle 07730 movement is a manual wind movement with a sweep second hand. It was typically used around the year 1945.
The Kienzle 07730 features the following functions:
- Manual Winding
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 2033 | Ordinary/None | Buy staff |
| 3374 | Incabloc | Buy staff |
| 3124 | Supershock | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.55 x 0.100 x 250 x 8.5 mm | Manual | Buy mainspring | |
| 1.50 x 0.105 x 280 x 9.0 mm | GR41332 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
