Kienzle 051E53
Ligne: 10.5'''
Jewels: 15/17
Lift Angle: 52°
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1935
Diameter: 23.3 mm
Hands: 1.40 x 0.80 mm
Base: Felsa 71
The Kienzle 051E53 is a manual wind mechanical watch movement with a bimetallic screw balance. It shares certain similarities with other Felsa movements, such as the 71, 73, 75-80, 144, 166, 167, 203, 205, 216, 219, 240, 244, 255, 268, 284, 286, 287, and 326. It features sub second and sweep seconds functions and was commonly used during the period around 1935.
The Kienzle 051E53 features the following functions:
- Manual Winding
- Sub Second
- Sweep Seconds
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.70 x 0.200 x 440 x 15.0 mm | GR5107 | Manual | Buy mainspring |
| 1.70 x 0.100 x 320 x 9.0 mm | GR4880 | Manual | Buy mainspring |
| 1.70 x 0.100 x 290 x 9.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
