Jaeger Lecoultre 910
(JLC, Lecoultre)
Ligne: 11.5'''
Jewels: 17/21
Power Reserve: 38 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1965
Diameter: 26 mm
Hands: 1.50 x 0.90 x 0.22 mm
The Jaeger Lecoultre 910 watch movement is a manual wind mechanism that features a sweep second function. It also includes a curved day display situated at the 6 o'clock position, and a date function that can be adjusted by changing from 20:30 to 24 hours. This movement was employed around the period of approximately 1965.
The Jaeger Lecoultre 910 features the following functions:
- Date: set by changing 20:30-24 hours
- Day: curved at 6 o'clock
- Manual Winding
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.10 x 0.110 x 290 x 9.5 mm | Manual | Buy mainspring | |
| 1.10 x 0.120 x 280 x 9.0 mm | GR2650 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
