Jaeger Lecoultre 489/1
(JLC, Lecoultre)
Ligne: 7.75'''
Jewels: 17
Lift Angle: 52°
Power Reserve: 40 hrs
Frequency: 21600 vph
Type: Manual Wind
Period used: ~1965
Diameter: 17.5 mm
Height: 2.85 mm
Hands: 1.20 x 0.60 mm
The Jaeger Lecoultre 489/1 watch movement features a Girocap combined setting for the escapement wheel, with the escapement and barrel designed differently from the Felsa 4122 movement. It is a manual wind movement that offers an optional sub-second function. It is equipped with Incabloc Shock Protection and was commonly used around the year 1965.
The Jaeger Lecoultre 489/1 features the following functions:
- Incabloc Shock Protection
- Manual Winding
- Option: sub second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.25 x 0.070 x 6.5 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
