Jaeger Lecoultre 488
(JLC, Lecoultre)
Ligne: 19.5'''
Jewels: 7
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1980
Diameter: 44.8 mm
Height: 9.5 mm
Hands: 1.50 x 0.35 / 1.35 mm
The Jaeger Lecoultre 488 watch movement is an open face calibre available with either a pin or pallet lever option. It features a stop- and split-second function implemented with pillar wheels. In cases where the pallet lever option is chosen, the movement is equipped with a barrel containing Geneva stopwork. Additional functions of this movement include a timer rattrapante with 60-second precision (0.2 seconds accuracy) and a 30-minute duration, facilitated by a pillar wheel. An optional variation grants a timer rattrapante with 30-second precision (0.1 seconds accuracy) and a 15-minute timespan. The movement also contains an addition timer, can be wound via the stem, features a sweep second hand, and includes a jeweled lever. It was used in watches produced around 1980.
The Jaeger Lecoultre 488 features the following functions:
- Addition timer
- Option: 30s (0.1s), 15min
- Split second function
- Stem wind
- Sweep second
- Timer Function
- Timer rattrapante: 60s (0.2s), 30min, pillar wheel
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|---|---|---|
| BRAKE SPRING | X/4429 | Buy part | |
| CORR. SPRING | X/4421 | Buy part | |
| OPERATING LEVER SPRING | X/4804 | Buy part | |
| PILLAR WHEEL, 6 TEETH | X/614 | 8070 | Buy part |
| SCREW | M/961 | 5401/28 | Buy part |
| WHIP SPRING | X/4229 | 51/720 | Buy part |
