Jaeger Lecoultre 483
(JLC, Lecoultre)
Ligne: 11.5'''
Jewels: 17
Power Reserve: 45 hrs
Frequency: 21600 vph
Type: Manual Wind
Period used: 1972-1979
Diameter: 26 mm
Height: 3.7 mm
Hands: 1.50 x 0.90 x 0.21 mm
The Jaeger Lecoultre 483 watch movement, produced from 1972 to 1979, incorporates optional plastic bushings instead of dial screws. It is a manual wind movement with a quickset date function achieved by pushing the crown repeatedly. The movement also features Incabloc Shock Protection and includes a calendar. Notably, the Jaeger Lecoultre 483 movement does not include a second hand.
The Jaeger Lecoultre 483 features the following functions:
- Calendar
- Date: quickset by repeated pushing the crown
- Incabloc Shock Protection
- Manual Winding
- Without Second Hand
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.20 x 0.105 x 9.5 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
