Jaeger Lecoultre 463
(JLC, Lecoultre)
Ligne: 14'''
Jewels: 17
Power Reserve: 41 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: 1937-1970
Diameter: 31.8 mm
Height: 6.2 mm
Hands: 1.85 x 1.30 x 0.25 / 0.27 x 0.20 mm
The Jaeger Lecoultre 463 is a manual-wind chronograph watch movement that was produced from 1937 to 1970, with over 3.5 million units manufactured during this period. It features various chrono mechanisms, and its parts are occasionally interchangeable, which resulted in series produced with parts from different calibres such as the 148, which has a larger pillar plate. The Jaeger Lecoultre 463 movement includes functions such as a 60-second chronograph, 30/45-minute chronograph, sub-second display, and switching through a cam mechanism.
The Jaeger Lecoultre 463 features the following functions:
- Chronograph Movement
- Manual-wind chronograph, 60s, 30/45min, cam switched
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 1225 | Ordinary/None | Buy staff |
| 5376 | Incabloc | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.35 x 0.145 x 380 x 12.0 mm | GR3530 | Manual | Buy mainspring |
| 1.35 x 0.140 x 360 x 12.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
