Jaeger Lecoultre 416
(JLC, Lecoultre)
Ligne: 17'''
Jewels: 15
Power Reserve: 34 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1930
Diameter: 37.8 mm
Height: 3.85 mm
Hands: 1.75 x 1.10 / 0.22 mm
Base: Cyma Tavannes 797
The Jaeger Lecoultre 416 is an open face calibre watch movement with a Breguet hairspring. The differences between the 325, 2029, and 2561 are not disclosed. The movement features functions such as stem wind and set, as well as a sub second hand. It was commonly used around the 1930s.
The Jaeger Lecoultre 416 features the following functions:
- Stem wind and set
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.40 x 0.180 x 480 x 15.5 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
