Henzi Pfaff 424
Ligne: 17'''
Jewels: 15
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1925
Diameter: 38.15 mm
Height: 4.1 mm
Hands: 2.00 x 1.10 / 0.28 mm
The Henzi Pfaff 424 is a hunter calibre mechanical watch movement, designed for stem winding and setting functions. It features a bimetallic screw balance with two adjustment screws and is equipped with a Breguet hairspring. This movement includes a subsidiary seconds display. It was introduced around 1925.
The Henzi Pfaff 424 features the following functions:
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.65 x 0.180 x 450 x 15.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
