Hamilton 74
Ligne: 13.25'''
Jewels: 17
Lift Angle: 52°
Power Reserve: 46 hrs
Frequency: 28800 vph
Type: Automatic
Period used: 1990-
Diameter: 30.4 mm
Height: 7.9 mm
Hands: 2.00 x 1.20 x 0.25 / 0.18 x 0.18 x 0.18 mm
Base: Valjoux 7750
The Hamilton 74 watch movement is an automatic chronograph with functions for measuring time in 60 seconds, 30 minutes, and 12 hours, using a cam switching mechanism. It features a sub-second function and a quickset date feature. The movement is mechanical and includes a hack feature, allowing for precise time setting. It has been used in watches since 1990.
The Hamilton 74 features the following functions:
- Automatic chronograph, 60s, 30min, 12h, cam switched
- Date: quickset
- Hack feature
- Mechanical Movement
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.50 x 0.113 x 600 x 12.0 mm | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
