Hamilton 04
Ligne: 11.5'''
Jewels: 17/21/25
Power Reserve: 40 hrs
Frequency: 21600 vph
Type: Automatic
Period used: 1971-1977
Diameter: 26.05 mm
Height: 5.6 mm
Hands: 1.50 x 0.90 x 0.21 mm
Base: Puw 1563
The Hamilton 04 watch movement, produced from 1971 to 1977, is a detached manual wind movement with automatic functionality and a sweep second hand. Its additional functions include day and date features that can be set by adjusting the time to 17:30-24h for the day and by repeatedly pushing the crown for quickset date changes.
The Hamilton 04 features the following functions:
- Automatic Winding
- Date (quickset by repeated pushing the crown)
- Day (set by changing 17:30-24h)
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.20 x 0.100 x 10.0 mm | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
