Gruen 826
Ligne: 19.5'''
Jewels: 1
Power Reserve: 12 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1994
Diameter: 44.8 mm
Height: 8.6 mm
Hands: 1.32 / 1.32 mm
The Gruen 826 is an open face calibre watch movement featuring a pin-lever escapement and a stop function with a pillar wheel. Its functions include a timer with a range of 60 seconds (0.2 seconds) and 30 minutes, activated by the pillar wheel. Additionally, there is an optional timer with a range of 30 seconds (0.1 seconds) and 15 minutes. The movement is stem wind and also features a sweep second hand. This movement was utilized around the period of 1994.
The Gruen 826 features the following functions:
- Option: 30s (0.1s), 15min
- Stem wind
- Sweep second
- Timer, 60s (0.2s), 30min, pillar wheel
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.95 x 0.200 x 15.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
