Girard Perregaux 62.4
Ligne: 16.5'''
Jewels: 15
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1940
Diameter: 37.2 mm
Height: 4.9 mm
Hands: 2.00 x 1.15 / 0.27 mm
The Girard Perregaux 62.4 is an open face calibre watch movement with varying bridge shapes. It is likely to have a left handed ratchet-wheel screw. Not much is known about the differences between the Girard Perregaux 62.4 and other similar movements such as the 283, 291, 297, 309, 329, 337, and 499. The Girard Perregaux 62.4 movement is designed for stem winding and setting, features a sub-second function, and was commonly used in watches around 1940.
The Girard Perregaux 62.4 features the following functions:
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.90 x 0.170 x 460 x 15.0 mm | Manual | Buy mainspring | |
| 1.90 x 0.170 x 460 x 14.0 mm | GR5608 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
