Framelec FR 304
Ligne: 10.5'''
Jewels: 15
Power Reserve: 36 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1934
Diameter: 23.3 mm
Height: 4.3 mm
Hands: 1.20 x 0.80 / 0.20 mm
The Framelec FR 304 is a manual wind mechanical watch movement that features a sub-second function. It was introduced around 1934. Technical differences between the Framelec FR 304 and other related movements such as the 294, 297, and 316 are not known.
The Framelec FR 304 features the following functions:
- Manual Winding
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.65 x 0.100 x 290 x 9.0 mm | Manual | Buy mainspring | |
| 1.60 x 0.095 x 320 x 9.0 mm | GR4477 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
