Fontainemelon 706
(Font)
Jewels: 7/11/15/17/19
Power Reserve: 40 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: 1897-1918
Diameter: 41.49 mm
Height: 4.1 mm
Hands: 1.50 x 0.80 / 0.18 mm
The Fontainemelon 706 watch movement is a hunter calibre movement that was in use from 1897 to 1918. It features a bimetallic screw balance and a Breguet hairspring. The movement has functions for stem winding and setting, as well as a sub-second hand.
The Fontainemelon 706 features the following functions:
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
