Fontainemelon 702
(Font)
Ligne: 18.5'''
Jewels: 15
Power Reserve: 41 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1940
Diameter: 41.65 mm
Height: 5.3 mm
Hands: 2.00 x 1.15 / 0.27 mm
The Fontainemelon 702 is an open face calibre movement that offers optional Breguet hairspring and varying bridge shapes. It likely features a left-handed ratchet-wheel screw, although further details are not available. Additionally, there is limited information on the differences between the 231, 235, 239, 243, 249, 255, 259, 265, 271, 277, 447, 449, 471, 477, and 508 models, which are likely catalog designations for varying bridge shapes. The movement includes stem winding and setting functions, a sub-second display, and was commonly used around 1940.
The Fontainemelon 702 features the following functions:
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 2.10 x 0.210 x 490 x 17.0 mm | Manual | Buy mainspring | |
| 2.10 x 0.210 x 480 x 16.0 mm | GR6106 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
