Fontainemelon 609
(Font)
Ligne: 18'''
Jewels: 15
Power Reserve: 30 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: 1885-1897
Diameter: 40.9 mm
Height: 7.0 mm
Hands: 1.82 x 0.70 / 0.24 mm
The Fontainemelon 609 watch movement is an open face calibre that was produced during 1885-1897, with a total of 8700 units manufactured. It features a bimetallic screw balance with four adjustment screws and a Breguet hairspring. The movement also includes a barrel with Geneva stopwork. Moreover, it offers the functions of stem wind and pin set, as well as a sub second indicator.
The Fontainemelon 609 features the following functions:
- Stem wind and pin set
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
