Fontainemelon 3
(Font)
Ligne: 10.5'''
Jewels: 15
Power Reserve: 44 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1940
Height: 4.0 mm
Hands: 1.40 x 0.70 / 0.21 mm
The Fontainemelon 3 watch movement is characterized by varying bridge layouts, some of which are likely labeled as FHF 150. It has different designations listed in old data sheets, including 151, 156, 158, 159, 162-164, 166, 174, 178, 187, 201, 203, and 208. Additionally, an optional 11.5''' size is available. This movement offers the following functions: manual wind, sub second, sweep seconds, and non-sweep seconds variations. It was commonly used around the period of 1940.
The Fontainemelon 3 features the following functions:
- Manual Winding
- Sub Second
- Sweep seconds and non-sweep seconds variations
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.80 x 0.100 x 320 x 9.0 mm | GR5254 | Manual | Buy mainspring |
| 1.80 x 0.100 x 300 x 9.0 mm | GR5253 | Manual | Buy mainspring |
| 1.80 x 0.100 x 290 x 9.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
