Fontainemelon 212
(Font)
Ligne: 13'''
Jewels: 15
Power Reserve: 45 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1955
Diameter: 29.4 mm
Height: 3.8 mm
Hands: 1.50 x 0.80 / 0.20 mm
The Fontainemelon 212 watch movement, commonly signed as 26, is similar to other movements in the 261 series, including models 264, 269, 2610 through 2616, 2618, and 2619. Despite differences in bridge layouts, no further distinctions are known. The movement operates as a manual wind movement with a sub-second function. It was primarily used in watches manufactured around 1955.
The Fontainemelon 212 features the following functions:
- Manual Winding
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.70 x 0.110 x 390 x 11.0 mm | Manual | Buy mainspring | |
| 1.70 x 0.115 x 360 x 10.5 mm | GR4918 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
