Felsa 780
Ligne: 11.5'''
Jewels: 15
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1950
Diameter: 25.6 mm
Height: 3.8 mm
Hands: 1.50 x 0.80 / 0.20 mm
The Felsa 780 is a mechanical watch movement with manual winding and a subsecond function. Its specifications are similar to the A. Schild 1203, but with a smaller base plate and barrel. The Felsa 780 was commonly used in watches during the approximate period of 1950.
The Felsa 780 features the following functions:
- Manual Winding
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.70 x 0.110 x 320 x 10.0 mm | Manual | Buy mainspring | |
| 1.70 x 0.115 x 300 x 9.5 mm | GR4915 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
