Felsa 76
Ligne: 10.5'''
Jewels: 15/17
Lift Angle: 52°
Power Reserve: 54 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1945
Diameter: 23.4 mm
Height: 4.0 mm
Hands: 1.20 x 0.63 / 0.21 mm
Base: Marvin 565
The Felsa 76 watch movement is a manual wind movement with sub-second and sweep seconds functions. It features a shock device that is only axial. While the exact differences between the 540 and 565 movements are not known, the 540 movement was commonly used during the period around 1945.
The Felsa 76 features the following functions:
- Manual Winding
- Sub Second
- Sweep Seconds
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 1681 | Ordinary/None | Buy staff |
| 1682 | Incabloc | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.80 x 0.100 x 350 x 10.0 mm | Manual | Buy mainspring | |
| 1.80 x 0.090 x 360 x 9.0 mm | GR5235 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
