Excelsior Park 4
(Excelsior, EP)
Ligne: 8.75'''
Jewels: 7/15/17
Power Reserve: 45 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: 1935-1967
Diameter: 19.7 mm
Height: 3.45 mm
Hands: 1.20 x 0.65 / 0.18 mm
The Excelsior Park 4 watch movement was produced from 1935 to 1967, with a total production of fewer than 16,000,000 units. It does not include a separate escape-wheel cock, distinguishing it from other movements in the same family. Variations existed in the balances used, but the differences were minor enough that parts could be interchanged. The movements within this family, including the 970, 980, 987, 999, 1014, 1036, 1047, 1056, 1090, 1210, 1217, 1251, 1254, 1276, 1375, and 1386, have similar appearances and share a height of 3.0mm. The Excelsior Park 4 movement is manually wound and features a sub-second function.
The Excelsior Park 4 features the following functions:
- Manual Winding
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.60 x 0.080 x 250 x 7.5 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
