ETA 2824-1
Ligne: 11.25'''
Jewels: 17/28
Lift Angle: 51°
Power Reserve: 47 hrs
Frequency: 21600 vph
Type: Automatic
Period used: 1962-1967
Diameter: 25.6 mm
Height: 4.0 mm
Hands: 1.40 x 0.90 x 0.21 mm
The ETA 2824-1 watch movement, used from 1962 to 1967, features an indirectly driven minute and automatic gear integrated into the movement, allowing for a low profile design. It includes a ratchet on the dial side and a crown mechanism with a rocker bar. The movement includes a relatively small rotor ball bearing and incorporates various functions, including automatic winding and a sweep second hand. Additionally, it utilizes an offset center wheel.
The ETA 2824-1 features the following functions:
- Automatic Winding
- Sweep second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
