Enicar 197
Ligne: 13.5'''
Jewels: 17
Power Reserve: 42 hrs
Frequency: 19800 vph
Type: Automatic
Period used: 1942-1949
Diameter: 30.5 mm
Height: 4.55 mm
Hands: 1.40 x 0.65 / 0.15 mm
The Enicar 197 watch movement, part of the 28.10 and 30.10 family, was produced in large quantities, with over 1,300,000 units manufactured between 1943 and 1955. In 1949, it was renamed 30.10RA PC to 330. This automatic (bumper) movement features sub-second functionality and is equipped with Incabloc Shock Protection. Its period of use spans from 1942 to 1949.
The Enicar 197 features the following functions:
- Automatic (bumper)
- Incabloc Shock Protection
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.10 x 0.095 x 300 x 9.0 mm | GR2605X | Auto | Buy mainspring |
| 1.10 x 0.100 x 280 x 9.0 mm | GR2613X | Auto | Buy mainspring |
| 1.10 x 0.100 x 250 x 8.5 mm | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
