Elgin 997
Ligne: 10.5'''
Jewels: 0/1
Lift Angle: 52°
Power Reserve: 32 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1975
Diameter: 24.25 mm
Height: 4.5 mm
Hands: 1.80 x 1.10 x 0.18 mm
The Elgin 997 watch movement, which was used approximately in 1975, features a pin-lever escapement, an indirect minute, hand friction clutch on the barrel, and modified balance cock and crown wheel over time. It offers manual winding and includes a sweep second function. Additionally, it utilizes the Pin Lever technology.
The Elgin 997 features the following functions:
- Manual Winding
- Pin lever
- Sweep second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.50 x 0.110 x 300 x 9.0 mm | GR4149 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
