Elgin 752
Jewels: 17
Power Reserve: 34 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: 1910-1945
Diameter: 43.1 mm
Height: 6.65 mm
Hands: 1.65 x 0.92 / 0.25 mm
The Elgin 752 watch movement, produced between 1910 and 1945, had a total production of 357,700 units. It features an open face calibre, specifically the model 7. This movement is equipped with a bimetallic screw balance and a Breguet hairspring. The negative stem mechanism allows for switching between winding and setting in the lever position, similar to other models like the 210, albeit with a modified escapement. Additional functions of this movement include stem winding, which can be switched by the crown or lever, as well as a sub second display.
The Elgin 752 features the following functions:
- Stem wind, switching by crown or lever
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 2.60 x 0.200 x 540 x 17.0 mm | DBH | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|---|---|---|
| BALANCE COMPLETE | 4081/ELG | 4081/ELG | Buy part |
| COLLET, HAIRSPRING BREGUET | 1318/ELG | Buy part | |
| HAIRSPRING, BREGUET STRENGTH 3 | X796/ELG | Buy part | |
| JEWEL, BALANCE HOLE 11 | 12BB/4 | 12BB/4 | Buy part |
| JEWEL, BALANCE HOLE P12 | 12BB/5 | 447/ELG P12 | Buy part |
| JEWEL, U/L BALANCE HOLE PVT 12 | 447/ELG .12 | CAB 53/ELG | Buy part |
| MAINSPRING 2.60-.20-540 17 | MS-JA105 | GR 6801-DBH | Buy part |
| STAFF, NEW .63 ROLLER 5.33 OA | 22BB/7 | 861/ELG P11 | Buy part |
